Screw Air Compressor (variable speed)

Screw Air Compressor (Variable-Speed)

Innovative solutions for specific air compression requirements are rotary type screw variable speed compressors. They provide unparalleled efficiency with its variable speed technology, which matches output to demand and saves energy and operating expenses. These compressors provide constant performance in a range of applications and are known for their dependability and longevity. Because of their adaptability, they are perfect for industries where a flexible air supply is necessary to ensure maximum output. Rotating screw variable speed compressors, which embrace state-of-the-art engineering, are the ultimate in air compression technology, providing unmatched efficacy in meeting changing industrial demands

WHY HANVI COMPRESSORS PVT LTD.

Screw Air Compressor variable speed

Energy Efficiency: Variable speed control adjusts motor speed to match air demand, reducing energy consumption during low-demand periods.

Constant Pressure: Maintains steady air pressure, enhancing equipment performance and minimizing production disruptions.

Flexibility: Adaptable to fluctuating air demand, ensuring optimal operation across varying workloads.

Longer Equipment Lifespan: Reduced wear and tear on components due to smoother operation and less frequent cycling.

Quiet Operation: Variable speed control reduces noise levels compared to fixed-speed compressors, creating a more comfortable work environment.

Cost Savings: Lower energy consumption and reduced maintenance requirements result in long-term cost savings for businesses.

MODEL	MOTOR		AIR DISPLACEMENT	FREE AIR DELIVERY		WORKING PRESSURE	AIR OUTLET	NOISE LEVEL	Oil Volume	DIMENSIONS	WEIGHT
	KW	HP	M3/MIN	CFM	M3/Min	Bar		dB(A)	Ltr	*(LWH)*	Kg
HSC-10PM	7.5	10	1.2	42	1.20	7	3/4”	60±2	10	900680800	220
			1.1	39	1.10	8
			0.9	33	0.93	10
			0.8	28	0.80	12
HSC-15PM	11	15	1.9	71	2.01	7	1″	62±2	16	1100730980	350
			1.7	64	1.81	8
			1.6	56	1.60	10
			1.4	49	1.40	12
HSC-20PM	15	20	2.5	98	2.78	7	1″	62±2	16	1100730980	360
			2.3	91	2.58	8
			2.1	83	2.35	10
			1.9	74	2.10	12
HSC-25PM	18.5	25	3.2	121	3.43	7	1″	64±2	18	12008801080	510
			3	114	3.23	8
			2.7	98	2.78	10
			2.4	85	2.40	12
HSC-30PM	22	30	3.8	143	4.05	7	1″	64±2	18	12008801080	510
			3.6	139	3.94	8
			3.2	117	3.31	10
			2.7	98	2.78	12
HSC-40PM	30	40	5.3	203	5.75	7	1 1/2″	66±2	30	14609801230	650
			5	186	5.27	8
			4.5	174	4.93	10
			4	147	4.16	12
HSC-50PM	37	50	6.8	252	7.14	7	1 1/2″	66±2	30	14609801230	700
			6.2	239	6.77	8
			5.6	210	5.95	10
			5	189	5.35	12
HSC-60PM	45	60	7.4	308	8.73	7	1 1/2″	66±2	30	14609801230	780
			7	284	8.05	8
			6.2	263	7.45	10
			5.6	225	6.37	12
HSC-75PM	55	75	10	382	10.82	7	2″	68±2	65	175012801590	1250
			9.2	357	10.11	8
			8.5	330	9.35	10
			7.6	268	7.60	12
HSC-100PM	75	100	13.4	520	14.73	7	2″	68±2	65	175012801590	1350
			12.6	495	14.02	8
			11.2	454	12.86	10
			10	394	11.16	12
HSC-125PM	90	125	16.2	572	16.20	7	2″	70±2	72	245016601700	1950
			15	530	15.00	8
			13.8	487	13.80	10
			12.3	434	12.30	12
HSC-150PM	110	150	21	741	21.00	7	2 1/2″	70±2	90	245016601700	2200
			19.8	699	19.80	8
			17.4	614	17.40	10
			14.8	522	14.80	12
HSC-175PM	132	175	24.5	865	24.50	7	2 1/2″	70±2	90	245016601700	2500
			23.2	819	23.20	8
			20.5	724	20.50	10
			17.4	614	17.40	12

Features:

👉 Higher efficiency since no electrical energy is used or lossses incurred for developing or maintaining the motors magnetic field * Intelligent Control System
👉 Less bearing current due to large air gap
👉 The Latest Generation Super Stable Inverter
👉 Wide Working Frequency Range To Save Energy
👉 Small Start-up Impact
👉 low temperature due to less rotor losses
👉 Low Noise
👉 Ramp up time, shorter, constant power up to maximum speed.
